Corvette and Camaro race cars co-developed with street counterparts
Corvettes C7.R competing in TUSC and Camaros Z/28.R competing in CTSCC closely resemble their counterparts built for the street.
It’s no coincidence that the Chevrolet Corvette C7.R competing in the TUDOR United SportsCar Championship and the Chevrolet Camaro Z/28.R racing in the Continental Tire SportsCar Challenge closely resemble their counterparts built for the street.
The racing Corvette was actually co-developed with the new 2015 Corvette Z06, with the two cars representing the closest link in modern times between Corvettes built for racing and the road, sharing unprecedented levels of engineering and components including chassis architecture, engine technologies and aerodynamic strategies.
Corvette Racing sets the gold standard for technology transfer between the track and street,
“When it comes to endurance racing, Corvette has been the benchmark of success for nearly 15 years,” said Jim Campbell, U.S. vice president, Performance Vehicles and Motorsports. “A great deal of the team’s success can be attributed to the symbiotic relationship between Corvette Racing and the production vehicles. The 2015 Corvette Z06 and new C7.R are more competitive on the street and track due to successful design of the Corvette Stingray – which itself is heavily based on the C6.R race car.”
A key part of the team’s success is the technology transfer between Corvette production cars and race cars.
“Corvette Racing sets the gold standard for technology transfer between the track and street,” said Tadge Juechter, Corvette chief engineer. “We are continually taking what we learn in competition, and applying it to improve production Corvettes – which then make better race cars. As a result, the new Corvette Z06 is the most track-capable production Corvette ever while the new C7.R is poised to be even more competitive on the race circuit.”
Many of the architectural and aerodynamic features of the C7.R are based on equivalent components and technologies from the 2015 Corvette Z06, including:
New, aluminum frame
As before, the race car and the Z06 share the same, production-based aluminum frame. However, for the first time, the frames for the race car and production Z06 are built in-house at the Corvette’s Bowling Green, Ky., assembly plant.
By leveraging advanced manufacturing materials – such as laser welding, Flowdrill-machined fasteners and a GM-patented aluminum spot-welding process – the production structure is significantly stronger than its predecessor. For Corvette Racing, this equates to a race chassis for the C7.R that is 40 percent stronger than its predecessor.
“In the first lap in the C7.R, the drivers felt the increase in chassis stiffness,” said Mark Kent, director of Racing for Chevrolet. “The drivers instantly noticed that the C7.R handling was better over changing surface features and rough track segments. This is important as our drivers don’t always stay on the smooth pavement, and are constantly driving over curbing at corner apexes.”
The addition of direct fuel injection to the Corvette Z06 enables the technology to return to a Corvette race car for the first time since the end of the GT1 era in 2009. It offered greater efficiency, which can make a significant difference in long-distance endurance racing such as Daytona and Le Mans through fewer time-consuming pit stops.
“Direct injection offers two advantages for the race team,” said Kent. “First, it offers drivers more precise throttle control, so that even the smallest changes in the driver’s throttle position delivers a proportional response from the engine. Second, direct injection typically improves fuel economy about three percent. That could be enough to bypass one fuel stop during a 24-hour race. Given that races are often won and lost in the pits, a three-percent gain in fuel economy could translate to a significant advantage in track position.”
The aerodynamic strategies of the Corvette Stingray came directly from the previous Corvette race car, the C6.R – including the forward-tilted radiator, functional hood and front-quarter panel vents, and rear transmission and differential cooling intakes.
The Z06 and C7.R take that aerodynamic foundation to the next level, sharing aggressive strategies for increased cooling and aerodynamic downforce, including similar front splitters, rocker panels, and front- and rear-brake cooling ducts.
“We worked concurrently with the race team developing the aerodynamic packages for the Z06 and the C7.R,” said Juechter. “We even used the same modeling software to test both cars, enabling us to share data and wind-tunnel test results. As a result, the aerodynamics of the production Z06 produce the most downforce of any production car GM has ever tested, and we are closing in on the aero performance of a dedicated race car.”
There are, of course, differences between the race car and production Corvette Z06. For example, the C7.R carried over the powertrain from the C6.R, as the GT Le Mans (GTLM) rules limit the maximum displacement to 5.5L, and prohibit forced induction. By comparison, the new Z06 boasts a supercharged 6.2L engine estimated at 625 horsepower. Both engines, however, are based on the historic small block architecture.
The suspension on the C7.R is modified to accommodate wider racing tires and larger brakes, again part of the GT regulations.
On the aerodynamic side, one major difference is the shift away from U.S. National Advisory Committee for Aeronautics, or NACA, ducts on the C7.R. The C6.R used two NACA ducts, on top of the rear bodywork and near the position of the rear wheels, for cooling. For the new C7.R, there are now openings on each of the rear quarter panels, above the brake ducts, which draw air to help cool the race car’s transaxle and differential.
Additionally, one of the primary results of the C7.R’s aero detail is making the rear wing a more-significant part of the car’s aero package. A larger radiator inlet has the added benefit of generating smoother airflow over the rear wing and making its use more efficient to the handling and stability of the race car at high speed.
Camaro Z/28.R features many elements of its production counterpart
In the Continental Tire Challenge, the Camaro Z/28.R debuted in 2014 Grand Sport (GS) competition as one of the most production-based cars on the track, sharing aero, engine and even axle components with the new 2014 Camaro Z/28.
“The original Camaro Z/28 was designed for racing and became an iconic performance car through its hard-fought victories,” said Kent.
Developed alongside its production counterpart, the Z/28.R incorporates the same performance elements that made the 2014 Camaro Z/28 the most track-capable Camaro ever. To enhance grip, for example, the Z/28.R’s body shares the same downforce-generating aero package as the production model, including:
• Front splitter
• Rear spoiler with wickerbill
• Hood extractor vent
• Rockers, wheel-house extensions and front tire deflectors
• Belly pan
The Z/28.R is also powered by the same LS7 7.0L V-8 engine as the production Z/28 and employs the unique, helical-gear limited-slip rear differential found on the production model. It is standard in the Z/28, helping the driver put down more power to the pavement when exiting corners.
“Apart from series-mandated equipment and the specialized suspension components needed for endurance racing, the Z/28.R is as close to a production-spec race car as you’ll find,” Kent said.
