Saudi GP: Latest F1 technical images on display

Join us as we delve into the latest technical developments from the Saudi Arabia Grand Prix at the Jeddah Corniche Circuit, courtesy of Giorgio Piola and Sutton Images.

Saudi GP: Latest F1 technical images on display
Listen to this article

Click on the arrows in the images to scroll through them…

Mercedes W12 engine detail
Mercedes W12 engine detail
1/35
A fantastic overview of the Mercedes W12 rear end without the bodywork attached, showing not only the power unit installation but some of the gearbox casing and rear suspension. Also note the wrap-around support for the rear wing pillar.

Photo by: Giorgio Piola

Red Bull Racing RB16B rear wing detail
Red Bull Racing RB16B rear wing detail
2/35
Red Bull with its medium downforce spoon-shaped rear wing mounted ready for scrutineering – note the patches on the top flap’s surface near the DRS linkages.

Photo by: Giorgio Piola

Red Bull Racing RB16B rear wing detail
Red Bull Racing RB16B rear wing detail
3/35
Another angle of the Red Bull wing and the repairs made to the upper flap near the DRS linkage.

Photo by: Uncredited

Williams FW43B, Mercedes engine detail
Williams FW43B, Mercedes engine detail
4/35
A fantastic overview of the Mercedes power unit installation in the Williams FW43B, with the air-to-air intercooler mounted in the left-hand sidepod we can see all the boost pipework and its routing. It’s also interesting to see how the exhausts converge inside the gearbox casing.

Photo by: Erik Junius

Aston Martin AMR21 rear wing detail
Aston Martin AMR21 rear wing detail
5/35
A close up of the Aston Martin AMR21’s rear wing which utilises two swan-neck style pillars to help maintain rigidity and improve flow over the underside of the mainplane.

Photo by: Giorgio Piola

Alpine A521 rear wing detail
Alpine A521 rear wing detail
6/35
The freshly re-liveried Alpine A521 rear wing which also uses a twin swan-neck pillar arrangement.

Photo by: Giorgio Piola

Williams FW43B rear wing detail
Williams FW43B rear wing detail
7/35
The spoon-shaped rear wing of the Williams FW43B along with the double element T-Wing.

Photo by: Giorgio Piola

AlphaTauri AT02 rear wing detail
AlphaTauri AT02 rear wing detail
8/35
Medium downforce rear wing on the menu for AlphaTauri too, as it opts for one of the least complicated endplate designs on the grid.

Photo by: Giorgio Piola

Ferrari SF21 rear wing detail
Ferrari SF21 rear wing detail
9/35
Ferrari also opted for a medium downforce gentle spoon shaped rear wing for the challenges of the Jeddah circuit.

Photo by: Giorgio Piola

Mercedes W12 gearbox detail
Mercedes W12 gearbox detail
10/35
A fantastic shot of the Mercedes gearbox casing, rear crash structure, suspension and brakes before they’re installed on the car and the associated paraphernalia is connected. Note the keel shape of the gearbox casing which enables clearance for air to flow between it and the floor beneath.

Photo by: Uncredited

Red Bull Racing RB16B engine detail
Red Bull Racing RB16B engine detail
11/35
The saddle cooler arrangement on the RB16B is not unique, with other teams employing similar setups but as we can see here, Red Bull have worked extremely hard on packaging it and the surrounding components in order they have the smallest footprint.

Photo by: Uncredited

AlphaTauri AT02 engine detail
AlphaTauri AT02 engine detail
12/35
The saddle cooler arrangement on the AlphaTauri AT02 as a comparison, with a slightly different layout due to the way their ancillaries are laid out.

Photo by: Uncredited

Red Bull Racing RB16B front brake detail
Red Bull Racing RB16B front brake detail
13/35
Front brake duct design on the Red Bull RB16B incorporates a bypass channel for airflow taken in by the main inlet to be routed out through the wheel face without being encumbered by the heat generated by the brakes. This is assisted by the heat reflective paint applied to the bypass channel’s surface.

Photo by: Uncredited

Alfa Romeo Racing C41 engine detail
Alfa Romeo Racing C41 engine detail
14/35
A cooler mounted above the exhaust at the rear of the Alfa Romeo C41.

Photo by: Uncredited

Alfa Romeo Racing C41 rear wing detail
Alfa Romeo Racing C41 rear wing detail
15/35
The Alfa Romeo C41’s rear wing, complete with their tall swan-neck style mounting pillars.

Photo by: Uncredited

Alfa Romeo Racing C41 front brake detail
Alfa Romeo Racing C41 front brake detail
16/35
A shot of Alfa Romeo’s front brake duct without the drum attached gives us an indication as to how the airflow is transmitted through the assembly for both cooling and aerodynamic assistance.

Photo by: Uncredited

AlphaTauri AT02 front brake detail
AlphaTauri AT02 front brake detail
17/35
As a comparison the brake duct from the AlphaTauri which also features the outer collar to help direct the airflow.

Photo by: Uncredited

AlphaTauri AT02 rear brake detail
AlphaTauri AT02 rear brake detail
18/35
A shot of the internal elements that make up the rear brake assembly on the AlphaTauri AT02 – note the reflective material used to try and keep temperatures under control.

Photo by: Uncredited

AlphaTauri AT02 front brake detail
AlphaTauri AT02 front brake detail
19/35
On the front brake assembly of the AlphaTauri AT02 check out the level of detail that the team have gone into with their brake bell design. This not only helps with disc cooling and aerodynamic throughput it also reduces weight slightly.

Photo by: Uncredited

Ferrari SF21 front brake detail
Ferrari SF21 front brake detail
20/35
Ferrari’s front brake assembly which you’ll note how the internal pipework splits into two as it wraps around the caliper enclosure.

Photo by: Uncredited

Alpine A521 front wing detail
Alpine A521 front wing detail
21/35
Alpine's front wing – note the shape of the flap tips which alter the shape, velocity and direction of the Y250 vortex.

Photo by: Uncredited

Alpine A521 rear brake detail
Alpine A521 rear brake detail
22/35
The rear brake and suspension upright on the Alpine A521 – see how large the pipework and enclosure around the caliper is in order to deliver adequate cooling.

Photo by: Uncredited

Aston Martin AMR21 rear brake detail
Aston Martin AMR21 rear brake detail
23/35
The Aston Martin AMR21 rear brake and suspension upright for comparison, which has a larger inlet and similarly large enclosure around the caliper.

Photo by: Uncredited

Red Bull Racing RB16B front suspension detail
Red Bull Racing RB16B front suspension detail
24/35
A close up of some of the inboard suspension details on the Red Bull RB16B.

Photo by: Uncredited

Mercedes W12 rear brake detail
Mercedes W12 rear brake detail
25/35
A close up of the Mercedes W12 rear brakes and suspension from behind, note the tether connected to the upright – a detail we rarely see.

Photo by: Uncredited

Mercedes W12 engine detail
Mercedes W12 engine detail
26/35
A peek into the Mercedes garage as the W12 was prepared for action gives us a great view of the power unit, including the exhausts. Also note the stack of coolers mounted above the power unit, which is normally buried beneath a snorkel from the airbox.

Photo by: Uncredited

Alfa Romeo Racing C41 front suspension detail
Alfa Romeo Racing C41 front suspension detail
27/35
A close up of some of the inboard suspension elements on the Alfa Romeo C41.

Photo by: Uncredited

Lewis Hamilton, Mercedes W12
Lewis Hamilton, Mercedes W12
28/35
A great shot of the Mercedes W12 up on the stands as it was prepared for action – note the use of the fully-enclosed brake drums.

Photo by: Erik Junius

Aston Martin AMR21
Aston Martin AMR21
29/35
A similar shot of the Aston Martin AMR21 as it was prepared – check out the brake drum snoods used to help keep everything at the optimum temperature.

Photo by: Erik Junius

Mercedes W12 rear wing detail
Mercedes W12 rear wing detail
30/35
A nice shot of the Mercedes W12’s rear wing which appears, along with the crash structure, to have some of the deflection and load test apparatus attached.

Photo by: Erik Junius

Williams FW43B
Williams FW43B
31/35
Inboard suspension, power steering and brake cylinders are all on show in this picture of the Williams FW43B.

Photo by: Erik Junius

AlphaTauri AT02 diffuser detail
AlphaTauri AT02 diffuser detail
32/35
This close up of the AlphaTauri AT02 gives us a fantastic view of the diffuser, rear suspension, exhausts and rear wing.

Photo by: Erik Junius

Ferrari SF21 diffuser detail
Ferrari SF21 diffuser detail
33/35
Similarly this shot of the Ferrari SF21 gives us a view of those items but also highlights the large cooling outlet chosen by the team.

Photo by: Erik Junius

Ferrari SF21 cockpit
Ferrari SF21 cockpit
34/35
An overview of the front of the Ferrari SF21’s steering wheel with its various buttons, rotaries and switches.

Photo by: Erik Junius

Aston Martin AMR21
Aston Martin AMR21
35/35
As a comparison we can take a look at the Aston Martin AMR21 steering wheel too.

Photo by: Erik Junius
