How Mercedes has turned the tables on Ferrari

shares
comments
How Mercedes has turned the tables on Ferrari
Giorgio Piola
By: Giorgio Piola
Co-author: Matthew Somerfield
Oct 3, 2018, 8:46 AM

Understanding, unlocking and managing tyre performance has always been an artform in modern Formula 1 and can often make a big difference in the performance between teams.

That becomes especially true towards the end of a season when those teams have got on top of matters start to pull away from those that have not.

It's a topic that's been central to Mercedes's quest for improvement ever since its return to the sport in 2010 – having been through phases whether it has hugely struggled to stop the rears overheating and then other times when it has been fully in control of things.

Even during its dominant recent spell it has particularly struggled to stay on top of the tyre situation at slower street circuits, with its concept better able to stretch its leg at high-speed medium downforce venues.

However, knowing that there was an area of weakness that needed addressing, Mercedes has focused a lot of effort in better sorting its tyre management for this type of venue – and judging by its success in Singapore and Russia it has certainly delivered.

Mercedes AMG F1 W09 brakes duct

Mercedes AMG F1 W09 brakes duct

Photo by: Giorgio Piola

As has been discussed before, the introduction of the finned rear wheel design in Spa, coupled with a new rear brake drum design, plus a change in mindset to setup and operate its suspension has turned the W09 into a great all-round machine, knocking Ferrari's SF71H off a perch it had seemed to occupy.

But Mercedes' development appetite in other areas of the car has not stopped either – as the team had yet further optimisations to its front wing package for Sochi, along with a revised rear wing support pillar layout.

Mercedes W09 rear wing pillar comparison

Mercedes W09 rear wing pillar comparison

Photo by: Giorgio Piola

The front wing had clear changes in the area alongside the endplate, which is interesting given both alterations have an impact on the amount and strength of outwash being generated.

It's altogether plausible then that the team have encountered these gains whilst studying the reduced outwash effect that will be possible due to the regulation change next season.

Mercedes AMG F1 W09 front wing comparison

Mercedes AMG F1 W09 front wing comparison

Photo by: Giorgio Piola

The front wing's main cascade element, which was previously stood adrift of the endplate, now lines up against it, but in a higher position. A pair of canards can be found in behind, exploiting any flow that can be picked up from under the raised cascade position.

Mercedes-AMG F1 W09 barge board

Mercedes-AMG F1 W09 barge board

Photo by: Mark Sutton

The slots found in the outer 100mm of floor have become an area where teams have made the most changes and gains this season, and Mercedes' latest update resulted in the forwardmost slot reworked.

The slot in the sidepod deflector bodywork has been adjusted as a consequence too, in order to fulfill the necessary regulatory obligation.

The Russian GP also set the stage for tests of a new rear wing, which utilises a pair of supports rather than just one that intersects the exhaust pipe.

Mercedes F1 W09 rear extra pipe detail

Mercedes F1 W09 rear extra pipe detail

Photo by: Giorgio Piola

It's a design choice that its closest rivals have utilised all season and also features the swan-neck style upper connections to the mainplane, which improves flow to the underside of the wing.

Mounted between the two pillars, which are much thinner than their counterpart, is a new winglet, used to manipulate the direction of the surrounding airflow, shaping the exhaust plume, which would hopefully yield yet more performance.

The team chose not to race the design in the end though, instead opting for its lower downforce spoon shaped rear wing with the plainer, more complementary endplates.

Something that was retained was a change in position for the oil breather pipework, now sited alongside the crash structure and exiting just beneath the main exhaust outlet.

This might not seem like a considerable change at first glance but it could be Mercedes first salvo in addressing an issue caused by a need to vent oil vapor generated by the power unit to the atmosphere.

Ferrari powered teams have been venting their oil vapour through pipework that exits out of the crash structure, above the rain light, all season.

Whilst that may seem innocuous at first sight, F1 teams do not do things for no reason. In fact it's a relatively old trick, one that predates the type of PCV systems we have on road cars, whereby a 'road draft tube' would be placed in the car's slipstream in order to pull the gases out of the crankcase.

If we use this logic to explain the use on the Ferrari powered cars and Mercedes W09, we can see that they are respectively using the diffuser and exhaust to entrain the gases from the pipework, thereby improving power unit efficiency.
