Giorgio Piola's F1 technical analysis
Topic

Giorgio Piola's F1 technical analysis

Bite-size tech: Williams FW38 details

shares
comments
Bite-size tech: Williams FW38 details
By:
Co-author: Matt Somerfield
May 13, 2016, 7:55 AM

As covered in the post-Russian GP debrief, Williams made changes to its turning vanes in Russia.

Time in the pitlane with the FW38 in Spain affords a better view of the new vanes which are taller than their predecessors.

Whilst they retain the same number of vertical slots along their length, these have also been changed to suit the geometry and height alterations.



Williams FW38 noses comparison
Williams FW38 noses comparison

Photo by: Giorgio Piola



The new turning vanes take advantage of the changes already made by the team to its nose, which as we can see has had a significant impact on the length and height of the 'thumb' style nose tip, with the tip shortened by approximately 50mm.
